PRO1298 UNIVERSAL DIGITAL ANALOG AUDIO CONVERTER

PRO1298 UNIVERSAL DIGITAL ANALOG AUDIO CONVERTER
Code: 64550020

Additional Images

645500206455002064550020


Analog To Digital Converter(ADC)

  • Digital Output Type: Coaxial & Optical
  • Digital Audio Output Format: LPCM
  • Input Impedance: 47K ohms
  • Minimum Load Impedance: 75 ohms
  • Frequency Response: 96KHz sample rate

Digital To Analog Converter(DAC):

  • Digital Input Type: Coaxial & Optical
  • Support Digital Audio Format: LPCM
  • Input Impedance: 75 ohms
  • Minimum Load Impedance: 10K ohms
  • Frequency Response: 32 – 192KHz sample rate

Note: Due to international patents, certain sound formats, like Dolby, are not supported. Certain televisions (i.e. Samsung Series 6) do not allow the user to change sound options. This might mean that the PRO1259 cannot convert ‘patented’ sound formats affecting certain HD television channels. All standard definition television channels should be unaffected.

Downloads

PRO1298 manual (110kb)
