24W BLUETOOTH WALL PLATE AMP |

AV DISTRIBUTION, MULTIROOM AV DISTRIBUTION

24W BLUETOOTH WALL PLATE AMP

01458320

PRO1464WPA

CSR Bluetooth V5.0 aptXandreg;.

24W RMS Per Channel
50M open space Bluetooth range
Stereo Class D Amplifier
Stereo Aux Line Input
Unique Bluetooth ID and PW
24V DC 3A Power

Discontinued

Description

Resources

DESCRIPTION

Overview

24W Wall Plate Audio Amplifier with CSR Bluetooth® v5.0

The PRO1351WP was our first wall plate featuring an in-built, high efficiency, 15W amplifier. As Sheldon Cooper said in the Big Bang Theory, ‘everything is better with Bluetooth’, so we added Bluetooth®. The Pro1430WP takes things up a notch by increasing power to 24W and utilising Bluetooth®V5.0. This allows for password protection and a larger transmission range. This unit will easily power ceiling speakers like the Earthquake ACS3.0 or indoor/outdoor speakers like the Wintal Studio 5 speakers.

Another big feature of this Bluetooth® amplifier is every individual wall plate has unique ID, which helps to distinguish all the wall plates installed in the same area. The password to pair with the Bluetooth® amplifier is the same: 1234.

Specifications

Audio Inputs	Bluetooth® Receiver or stereo audio line level
Bluetooth® Version	Bluetooth® v4.2 compliant with aptX
Bluetooth® Receive Distance	50 Meters (open space)
Power Amplifier Type	Stereo Class-D
Output Power	24W (rms) per channel (@ RL=4Ω (Ohm))
THD+N	0.1% (@ RL=4Ω (Ohm), f = 1 kHz)
Minimum Load Resistance	4Ω (Ohm)
Power Source	24V DC / 3A included
Audio Priority	Bluetooth® > Line In
Mounting Depth	50mm
Features	Includes Speaker Protection circuit 3 min link-lost timeout function. Bluetooth® automatically switch to paring state if reconnecting fail

FAQs

Q: What is the passkey for Bluetooth connections?
A: The passkey for the PRO1430WP is 1234.
