CLEANING AND PROTECTIVE KIT

Remove dust particles with the included brush, use the cloth to clean your LCD screen, use the protective film to protect your cameras sensitive screen. The squeegee card canbe used to smooth out your protective film when used. The sandpaper stick will clean your memory card, mobile phone etc.

Kit includes:

A Brush
Cleaning fluid
Cleaning cloth
Squeegee card
Foam swabs
Protective films
Sandpaper stick

WALL PLATE RECEIVER FOR

PRO1247DSWP PLATE RECEIVER FOR PRO1247D

Spare receiver for PRO1247D in wall plate type, it includes the IR target in the box.

Features:

Allows you to add more zones to your existing HDTV over CAT5 AV distribution set up
Receives HD video and audio signals from the PRO1247D distribution hub from up to 120 metres
Transmits IR signals to remotely control AV devices
Power LED
Receives power via CAT5 connection with hub
Supports 480p/ 1080i

Connections:

2x RJ45 ports (back of the wall plate)
YPbPr video output (3x RCA)
Coaxial digital audio (DA) output (1x RCA)
Stereo audio (L/ R) output (2x RCA)
1x IR receiver input (3.5mm jack)

Specifications:

Video nominal input level: 1 Volt (peak to peak)
Video output impedance: 75 ohm
Audio output impedance: 300 ohm

Contents:

HDTV over CAT5 receiver
Dual band IR receiver

SPARE VGA+AUDIO DISTRIBUTION

PRO1270S RECEIVER FOR PRO1270 WITH LOOPOUT FUNCTION

Features:

Spare receiver for PRO1270
Transmission Distance up to 1000ft / 300m via single UTP CAT5/5e
CAT5 loopout function
Support 2X VGA+Audio Distribution Amplifier
EQ(Sharpness) and GAIN(Brightness) control are Adjustable
Provides Chainable Function up to 3 Units
12VDC switching mode power supply included
1x CAT5 input, 2x VGA+2×3.5mm stereo audio outputs
Distance via CAT5 Cable:
640*480 pixels    (VGA)—300M
800*600 pixels   (SVGA)—200M
1024*768 pixels   (XGA)—180M
1280*1024 pixels (SXGA)—120M
1600*1200 pixels (UXGA)—100M

8-WAY SPEAKER HUB

PRO1257 VOLUME CONTROL PARALLEL SPEAKER HUB

Features:

8 way speaker hub
Volume control in up to 8 rooms
Light weight
Screw terminals handle wire sizes form 24 to 12 gauge
Wall mountable
Small size and compact
Large detachable terminal block(supplied) for quick and easy installation in a structuredwiring
cabinet

Specification:

Dimensions:196L x 94W x 29.5H mm
Weight: 198 g

Installation considerations:

Calculate the impedance Matching settings.
Ensure optimal operation of your amplifier or receiver, your speakers must show it a
load that it can handle safely and effectively. This requires the use of impedance-matching
volume controls.

Cautions:

Every speaker pair in the system must be connected to an impedance-matching volume
control and set to the same magnification.
When you install the HUB and connect the volume controls to it, double check the switch
on the volume controls to verify that they are set correctly for the impedance load of your
speakers.

BLUETOOTH MUSIC TRANSCEIVER

Bluetooth receiver and transmitter in one!

Features:

Bluetooth 4.2
No app or driver needed
Noise reduction and echo cancellation
Multi-band equalizer configuration
Supports voice prompts
Built-in 400mAh Li-Ion battery
Built-in enhanced signal transmission circuit, connected fast and stable

SPECIFICATIONS:

Bluetooth Version	Bluetooth 4.2, Consume low power
Supported protocol	A2DP,AVRCP,HFP,SPP HID
Current consumption	<43MA(receiving Mode)
	<60MA(Transmitting Mode)
	<18MA(Stanby Mode)
Built-in battery	Polymer 400MAh
Charging current	300MA
playing period	8 hours
Bluetooth distance	10M
Interface	Micro USB / 3.5MM stereo audio port

RCA GROUND LOOP ISOLATOR

Ideal for long cable runs, or car audio installations where Ground Loop hums are an issue. Ground loops occur when2 or more pieces of equipment connect to "grounds"that have different voltage potentials (instead of a common voltage potential "ground" would suggest). If two pieces of audio equipment are plugged into different power outlets (say in the case where a subwoofer is connected somedistance from the AV system), there will often be a difference in their respective ground potentials creating the 50Hz mains hum we all hate.

The PRO1059 will solve the problem of ground loop issues and easily connects in any audio system!

Frequency range: 10~20,000 Hz
Insertion loss: 1dB @ 1kHz
Connection: RCA Sockets to RCA Plugs
Channel separation: 45dB @ 1kHz minimum

2 WAY STEREO SPEAKER SWITCH

Switch an audio source from Speaker Set A to Speaker Set B or Combine Both (A+B Speakers ), without overloading the trasistor output stages. This can be useful if you have speakers wired to another area in your home but have one audio source.

Features

1 input to 2 outputs
Select Speaker Set A, B or A+B (please check for impedance compatibility with your amplifier when using A+B)
Left (+/-) & Right (+/-) screw terminals for amplifier input
Select output to speakers set 1, speaker set 2, or both sets at the same time
10 watts per channel
1 Speaker on, 2 Speakers on OR All Speakers on
Designed with non-shorting selector switch so you can select between two speaker systems without overloading the output stages

Specifications

Audio power handling: 10 watts/ channel continues music power
Frequency response: 0.1 dB, from 20 Hz to 20kHz

Note: Impedance restriction for total speakers is 4 ohm. Therefore, you should ensure your system or amplifier will accept a 4 ohm load at the speaker output. Please find impedance chart from user manual at download section

VGA AND AUDIO OVER CAT5 BALUN AND

PRO1270 VGA+AUDIO OVER CAT5 DISTRIBUTION HUB

Features:

Distribute your VGA+Audio signal via single UTP CAT5/5e to up to 4 zones (8 outputs), each receiver has 2 outputs
Transmission Distance up to 1000ft / 300m via UTP CAT5/5e
With the loopout function on the receiver, it can be set up more than 4 zones.
350 MHz signal transmission bandwidth
Provides 4 ports RJ45 outputs for transmission
With local VGA & audio outputs
12VDC switching mode power supply included
1x VGA + 1x 3.5mm stereo audio input
1x VGA + 1x 3.5mm stereo audio output
4x CAT5 outputs
Distance via CAT5 Cable:
640*480 pixels    (VGA)—300M
800*600 pixels   (SVGA)—200M
1024*768 pixels   (XGA)—180M
1280*1024 pixels (SXGA)—120M
1600*1200 pixels (UXGA) —100M

8 PORT IR RECEIVER HUB

Connect up to eight IR Receivers to an IR Repeater (eg PRO1183). Design allows multiple IR Repeater Kits to be connected to multiple IR Receivers.

Features

Connect IR Repeater Kit (PRO1183) to up to eight IR Receivers via only 4 wires
Light weight
Screw terminals handle wire sizes form 24 to 12 gauge
Wall mountable
Small size and compact
One-in eight-out
Large detachable terminal block (supplied) for quickand easy installation in a structured wiring cabinet
No power supply required; takes +12VDC power from IRRepeater Kit PRO1183 and distributes it to IR Receivers
Design allows adding extra IR Repeater kits with minimal wiring (only IR and GND wires).
- Do not connect +12V line to more than one IR Repeater to the IR Receiver Hub to avoid damage to IR Repeater

Specifications:

Dimensions:196(L) × 92(W) × 30(H)mm
Weight: 198g

Images

Possible wiring configuration showing extra PRO1156 Kit connected.

SPARE HDTV DISTRIBUTION RECEVR

HDTV OVER CAT5 RECEIVER

To suit the PRO1247D HDTV over CAT5 distribution hub

Features:

The PRO1247DS allows you to add more zones to your existing HDTV over CAT5 AV distribution set up
Receives HD video and audio signals from the PRO1247D distribution hub from up to 120 metres
Transmits IR signals to remotely control AV devices
Power LED
Receives power via CAT5 connection with hub
Supports 480p/ 1080i
Can be wall mounted (screws included)

Connections:

2x RJ45 ports
YPbPr video output (3x RCA)
Coaxial digital audio (DA) output (1x RCA)
Stereo audio (L/ R) output (2x RCA)
1x IR receiver input (3.5mm jack)

Specifications:

Video nominal input level: 1 Volt (peak to peak)
Video output impedance: 75 ohm
Audio output impedance: 300 ohm
Power: 12V DC 1.2A switching power
Weight: 310gr
Dimensions: 158 (W) x 67 (D) x 31 (H) mm

Contents:

HDTV over CAT5 receiver
4x screws for mounting
Instructions
