The 5.1 Digital to Analog Audio Decoder uses a 24-bit / 96 kHz Digital Receiver & DSP, and a 192 kHz/24bit ADCto convert multi-channel digital audio formats to high-quality 5.1 analogue audio. It supports Dolby Digital (AC3), Dolby Pro Logic, DTS, PCM and other multi-channel digital audio format source formats. The optical or coaxial inputs allow easy connection to any equipment with digital output. A stereo analogue input is also provided for expanding up to all 5.1 channels. The DAD51 is perfect for older amplifiers without Dolby or DTS decoding!
Features
- Convert DTS/AC3 source digital audio to analog 5.1ch audio output
- Expand 2.0CH Analogue audio up to 5.1CH
- Multi-channel audio input (SPDIF, Coaxial)
- Input selector button
- Output mode selector button
- No need to install drivers
- Portable, flexible, plug and play
Specifications
-
Input ports:
- 2x Toslink/SPDIF
- 1x Coaxial
-
Output ports:
- 6x RCA (L / R / C / RL / RR / SW)
- Signal to Noise: 120 dB
- Degree of Separation: 85 dB
- Frequency Response: 20 Hz ~ 20 kHz ± 0.5 dB
- Dimensions: 105 x 75 x 25 mm
- Max Output Volt: 2.2Vp-p
- Power Supply DC/5V 1A
