Features
- Distributes 1 input HDMI signal to 4 identical synchronised UTP outputs
- Use single Cat5e/6 transmission distance up to 50m under 1080P @ 8-bit with 3D (the transmission distance for the receiver also need up to 50m)
- Supports Resolutions up to 1080p @ 60Hz
- Supports High Definition Audio: Dolby TrueHD, DTS-HD Master Audio
- Supports 30/36-bit Deep Colour display
- Supports 3D technology
- DC 5V power
Specifications
| Video Amplifier Bandwidth | 140 MHz |
| Input Video Signal | 0.5- 1.0 Volts P-P |
| Input DDC Signal | 5 volts p-p (TTL) |
| Data transfer speed rate | 6.75Gbps (Maximum) |
| Video Format Supported |
VGA: 640×480, 800×600, 1024×768, 1080×1024
DTV / HDTV: 480i / 576i / 480P / 576P / 720P / 1080i / 1080P 3D video support |
| Vertical Frequency range | 60Hz |
| Support Video Color Format | xv-YCC / Deep Colour 36-bit |
| Support Audio Format | DTS-HD / True-HD / LPCM7.1 / AC3 / DTS / DSD |
| Transmission Distance |
1080P 8-bit 50m
Over single Cat5e or Cat6 cable / 24 AWG / Solid |
| Power consumption | 12watts (Maximum) |
| Operating Temperature Range | -5 to +35° (+23 to +95°) |
| Operating Humidity Range | 5 to 90% RH (No Condensation) |
| Dimension (L×W×H) | L300 x W155 x H65mm |
| Net Weight | 490g |
