This Phono Preamplifier adds phono capability to any amplifier or receiver that has a spare AUX/CD/DVD Audio linelevel input. It can also be used to input a turntable directly into a mixer or computer soundcard. With its precise RIAA (Recording Industry Association of America) equalization, this preamp’s sound quality easily matches or exceeds that of the phono preamps found built into the highest quality stereo components. Its switch-selectable AUXenables easy selection for inputs, eliminating the need to connect and disconnect sources that share the input with this preamp.
Specifications:
| Input Impedance | 47K ohms |
| Output Impedance | 100 ohms |
| Phono Amplitude Gain | 40 dB (@1kHz) |
| AUX Amplitude Gain | 6 dB |
| Maximum Input | 50 mV pp |
| Output Level | 5V pp |
| Frequency Response | 20 Hz to 20k Hz |
| Signal to Noise Ratio | 70dB |
| Power Source | 12V DC (INCLUDED) |
| Size | 145mm (L) * 96mm (W) * 31mm (H) |
