PRO1351 BLUETOOTH AUDIO POWER AMP

Features

Use the PRO1351 to power in-ceiling speakers with the audio from any Bluetooth enabled device, or other source device such as computers, DVD players, and TVs! Perfect for permanent audio installations in entertaining areas, and even bedrooms

Ideal for installing where volume control is not intendedto be adjusted by end-users!

Ideal for use with:

  • Mobile devices with Bluetooth audio
  • DVD players
  • TV’s
  • Indoor/​Outdoor Speakers
  • In-ceiling/​in-wall Speakers
  • Bluetooth wireles audio receiver built-in
  • Switch between Bluetooth or 3.5mm (line) inputs
  • Compact design
  • Volume control
  • Suitable for 4Ω, 6Ω and 8Ω speakers
  • Includes Speaker Protection circuit

Specifications

.rpg_table { border-collapse: collapse; margin: 15px; } .rpg_table th, .rpg_table td { padding: 5px; line-height:30px; } .rpg_table td, .rpg_table th { text-align: left; vertical-align: top; border-top: solid 1px #cccccc; border-bottom: solid 1px #cccccc; } .rpg_table th, .rpg_table .header { font-weight: bold; text-align: left } .rpg_table th[align=center], .rpg_table td[align=center] { text-align:center !important; } .rpg_table .spacer { border: 0 !important; width:15px !important; } .rpg_table .no-wrap { white-space: nowrap !important; }
Audio Inputs Bluetooth Receiver or stereo audio line level
Bluetooth Receive Distance 10 Metres
Bluetooth Version 3.0 EDR compliant
Power Amplifier Type Stereo Class-D
Output power 15W (rms) per channel (@ RL=4 ohm)
THD+N 0.06 % (@ RL=8 ohm, f = 1 kHz)
Minimum Load Resistance 4 Ohm
Power Source 12 VDC/​2A (Power supply included)
