The HDMIIPLR HDMI over CAT6 Extender will send HDMI signal (up to 1080p@60Hz) with Deep Colour™ support over a single CAT6 cable to a distance of up to 100 metres.

Use the HDMIIPLR and the HDMIIPLRS Spare Receiver to create a system with up to 16 Sources (Transmitters) & 200 Outputs (Receivers)! IR Pass-through means no more running aseparate IR extender system to control your sources.

• HDCP Compliant
• Distribute HD signals in 576p / 720p / 1080p using a CAT6 cable
• 1080p resolution up to 100m/​330ft
• Create a transmitter/​receiver cascade to extend distance and build up a HDMI splitter system
• Easy installation via a single CAT6 cable
  – no need to adjust gain or equalizer settings
• IR pass-through function to switch HDMI source device, IR frequency range: 38-56kHz
• High quality metal chassis
• No video quality loss
• VESA compatible mounting holes
• LED source input display
• IR Remote control for changing receiver source

Connection Examples

One-to-One System

One-to-Many System

Many-to-Many System

I’m inputting 1080i resolution from my Foxtel IQ2, yet my display is receiving 720P. Is this correct?

The HDMIIPLR will output in 576P, 720P or 1080P. If your signal is 1080i, it will output 720P on the display.

What was our measured current draw for the transmitter and receiver?

The max. current draw that we measured was 1.1A (5V) for the transmitter and 0.9A (5V) for the receiver.

Is there 3D support?

Please note that the HDMIIPLR does not support 3D

I added a new receiver/​transmitter but I’m getting no picture

If you have added a new spare receiver (HDMIIPLRS) or transmitter to your existing setup and are getting no picture, or an "Invalid Format" message, just makesure that your source device is set to output either 720p or1080p.

Receiver Only: The HDMIIPLR HDMI over CAT6 Extender will send HDMI signal (up to 1080p@60Hz) with Deep Colour support over a single CAT6 cable to a distance of up to 100 metres.

Use the HDMIIPLR and the HDMIIPLRS Spare Receiver to create a system with up to 16 Sources (Transmitters) and 200Outputs (Receivers)! IR Pass-through means no more running aseparate IR extender system to control your sources.

• HDCP Compliant
• Distribute HD signals in 576p / 720p / 1080p usinga CAT6 cable
• 1080p resolution up to 100m/​330ft
• Create a transmitter/​receiver cascade to extend distance and build up a HDMI splitter system
• Easy installation via a single CAT6 cable
  – no need to adjust gain or equalizer settings
• IR pass-through function to switch HDMI source device, IR frequency range: 38-56kHz
• High quality metal chassis
• No video quality loss
• VESA compatible mounting holes
• LED source input display
• IR Remote control for changing receiver source

One-to-One System

One-to-Many System

Many-to-Many System

I’m inputting 1080i resolution from my Foxtel IQ2, yet my display is receiving 720P. Is this correct?

The HDMIIPLR will output in 576P, 720P or 1080P. If your signal is 1080i, it will output 720P on the display.

What was our measured current draw for the transmitter and receiver?

The max. current draw that we measured was 1.1A (5V) for the transmitter and 0.9A (5V) for the receiver.

Is there 3D support?

Please note that the HDMIIPLR does not support 3D

I added a new receiver/​transmitter but I’m getting no picture

If you have added a new spare receiver (HDMIIPLRS) or transmitter to your existing setup and are getting no picture, or an "Invalid Format" message, just makesure that your source device is set to output either 720p or1080p.

The HDMI extender includes two units: transmitter & receiver units. The Transmitter is used to capture the inputHDMI signals and carries the signals through two RJ-45 connectors into two low cost CAT6 cables. The receiver is responsible for equalizing the sent TMDS multimedia data.

We recommend the use of our DOSS TWIN CAT5E cable. It is insulated in a Black PVC Jacket and contains 2x CAT5E cables.

This is great for dual CAT5 HDMI Extenders as one cableis easier to install than two, and unique colouring allows easy identification of data lines.

Click here to see the product…

45M 1080p HDMI OVER DUAL CAT6 EXTENDER

Features

• Easy to use: Install in seconds, no need for advanced settings adjustments.
• One pair (transmitter and receiver) supplied as a fullfunctional module.
• Use UTP LAN cable (CAT6) to substitute HDMI cable to achieve long distance transmission.
• UTP cable termination follows the standard of IEEE-568B.
• Transmission distance reaches up to 45 metres under the video format of 1080P.
• LED indicators to show the power and video signal status.
• HDCP compliant.

• Video Format Supported:
  • 1080P
  • 1080i
  • 720P
  • 576P
  • 480P
  • 576i
  • 480i
• Transmission Length: 45m MAX @ 1080P
• Compression Rate: 2.25Gbps
• Operating Temperature Range: -15 to +55°C (-41 to +95°F)
• Operating Temperature Range -5 to +35°C (-41 to +95°F)
• Operating Humidity Range: 5 to 90 % RH (no condensation)
• Input Video Signal: 5 volts p-p (TTL)
• Power Supply: 5VDC
• Dimensions (WxHxD): 83mm x 46mm x 23mm
• Weight: 0.22 Kg

Q: The description says it uses CAT6 cable, but you recommended CAT5e cable – what’s the deal?
A: Over 40m there is not a big difference between CAT5e and CAT6 cable. Not to mention the built-in electronics of the HDMIC6 compensates for signal transmission losses etc. So inshort, CAT5e cable will work just fine – plus it’s cheaper!

A neat and simple high definition HDMI extender kit. This kit extends your high definition AV sources from Blu-ray DVD Players, PS3 and XBOX etc. up to a maximum 50m via single solid CAT5E / 6 cables through the wall cavities. The new EDID feature increases its compatiblilty with players or displays. It supports full 1080P high definition and integrates an infra-red control extender for full controllability from the receiving end. RJ45 connections on the rear of both units make it for easy connection.

• Transmits HDMI Audio/​Video Signals and IR over a 50m single solid Cat5e/​6 Cable.
• Transmits a wide-band Bi-Directional IR control signal together with the HDMI signal.
• Supports 24bit Deep Colour.
• Full cascade to create larger distributions.
• Automatically adjusts feedback, equalization and amplification
• EDID DIP switch on Transmitter to enhance EDID communication between sources and displays
• With adjustable EQ for optimizing the transmission signal
• Supports PCM, Dolby Digital, and DTS Digital Surround
• Follows IEEE-568B cable termination standards, solid cables are prefered
• HDCP compliant
• Supports 3D video format

Wiring Diagram

What are included in the package?

• 1xHDMI Transmitter
• 1xHDMI Receiver
• 2 x IR TX Emitter
• 2 x IR RX Receiver
• 2 x 5V / 1A DC Adapter (Australian approval)
• User Manual

*Note: 50m distance is under perfect transmission conditions including straight cable runs with no electrical interference, bends, kinks, patch panels or wall outlets.

Does this unit work with the new Foxtel iQ3?

Yes. Just make sure your IR emitter is placed in the correct location. See the image below.

Why is it not working well as it suppose to?

Please make sure IEEE-568B type solid cable is being used.
